Mityvac

MV8000

MV8000

Regular price $76.48 USD
Regular price Sale price $76.48 USD
Sale Sold out

This is the original Mityvac hand vacuum/pressure pump kit used by service professionals worldwide for performing hundreds of automotive diagnostic and mechanical tests and for one-person brake bleeding. The MV8000 kit contains our most popular Select line hand vacuum pump with vacuum gauge and accessories.

Includes:
  • Select line hand vacuum pump (Model No. MV8010) with 2" (50 mm) diameter gauge
  • 4.5 oz. (135 ml) fluid reservoir bottle with fluid transfer and storage lids
  • (7) Tapered adapters for connecting to tubing from .090" to .50" ID (2.3 mm to 13 mm)
  • (2) Tapered manifold plugs
  • (3) Bleed screw adapters
  • (2) 1/4" ID x 24" long (6.4 mm ID x 610 mm long) connection tubes
  • 5/32" ID x 1/4" ID (4 mm ID x 6.4 m ID) tubing adapter
  • 1/4" ID x 1 1/2" long (6.4 mm ID x 40 mm long) connection tube
  • 5/32" ID x 3" long (4 mm ID x 75 mm long) connection tube
  • 1/4" ID x 3 5/8" long (6.4 mm ID x 90 mm long) connection tube
  • Rubber cupped adapter
  • User manual (English/French/Spanish)
Specifications:
  • Packaged Weight: 1.2 lbs (0.54 kg)
  • Packaged Size: 12" x 10" x 1 1/4" (305 mm x 250 mm x 32 mm)
  • Pump Displacement:1 cu. in. (16 cc) per stroke
  • Max. Vacuum:25 in. Hg (85 kPa)
  • Max. Pressure: 25 psi (172 kPa)
  • Gauge Indication: 0 - 30 in. Hg (0 - 100 kPa)
